The Gizmo Board
Powerful. Expandable. Practically Unbelievable.

Power Switch Power Switch Power Jack 9VDC – 24VDC input voltage
Max VDCIN power: 48.5W @ 9V, 71W @ 24V
Power Regulator Circuits Programmable RAM for power regulator settings
9VDC – 24VDC input voltage
Max VDCIN power: 48.5W @ 9V, 71W @ 24V
20W max system board with USB KB/MS and boot from USB
10W max USB (2.5W per port)
5W max SATA HD
AMD A55E Controller Hub AMD A55E G-Series platform controller hub
PCIe interface: 4×1 Gen 2
PCI: 33MHz 4 slots
SATA: 6x 6Gb/s with RAID 0,1,5,10
USB: 14 v2.0, 2 v1.1
HD audio: up to 4 channels
102 max GPIOs
High Speed Connector Display port signals for second display
Two USB interfaces
One SATA interface
Two PCIe x1 interfaces
VGA Video Connector Resolution up to 1920x1200x30bpp NIC Controller (on back) Realtek RTL8111DL Gigabit Ethernet controller Fan Connector Fan not required with G-T40E APU
Fan power provided for G-T56N APU support
SPI ROM (on back) 64Mb Flash memory
Preloaded with SageBIOS (coreboot distribution)
Includes demo payload
SATA Data Connector On board SATA connector
Adjacent 5V SATA power connector
SATA Power Connector On board SATA connector
Adjacent 5V SATA power connector
Battery 3V coin battery
Required for proper operation
(Note: Errata on Rev 1 build 2 board requires battery to be inserted backwards)
Audio I/O Ports
Stereo input
4-channel output
Realtek Audio Controller High-definition Audio
Realtek ALC272
AMD G-Series APU AMD Embedded G-Series G-T40E APU
Dual core
1GHz operating frequency
6.4W thermal design power
1MB L2 cache
Integrated Radeon HD 6250 GPU
GPU frequency 280MHz
Board supports T56N APU (1.8GHz)
Low Speed Connector One USB interface
ADC input signal
DAC output signal
GPIO pins
PWM pins
SPI port
Counter
Reset
1GB DDR3 RAM 1GB DDR3-1066
DDR3-1333 compatible
Soldered down
Ethernet & 2 USB Ports Two Type A USB connectors
Standard Ethernet jack
USB Header (2ports) Standard 10 pin header
Two USB interfaces
SmartProbe Connector JTAG port access
